額定電壓0.6/1kV~ 3.6/6kV變頻電纜
額定電壓0.6/1kV~ 3.6/6kV變頻電纜

上一篇：耐熱鋁合金絞線及耐熱鋼芯鋁合金絞線下一篇：YJV8.7/15KW 1X400

詳情說明

用途/Application:變頻電纜

（又名變頻電力電纜）廣泛應用于變頻器與電動機之間的電力線路上，實現電動機的無極調速。電纜的額定電壓為0.6 /1kV~3.6/6Kv,變化的變頻為0Hz~400Hz或0Hz~61Hz，使電動機的轉速由低速調到高速快速平衡的調制。

Power supply conversion cable is widely

used in power supply,circuit between frequency converter

and electric motor so as to realize stepless speed

regulation of electric motor.With rated voltage of

0.6/1kV ~3.6/6Kv, changing frequency from 0Hz to

400Hz or from 0Hz to 610Hz, the cable

Allows the rotational speed of electric motor to vary

from low to high quickly and steadily.

特征/characteristics：

變頻電纜的特征有三相主線芯和三條中性線芯對稱分布，

并有兩層屏蔽體，即內層總屏蔽和外層總屏蔽。

Power supply conversion cable has three-phase master

line cores and three neutral cores,which

array symmetrically,and has two shielding bodies,

namely, the inner layer general and outer

layer general shield.

結構示意圖/Structural schematic diagram of cable

型號及名稱/ Model and Description

型號Model	名稱Description
BPVVPP2	聚氯乙烯絕緣聚氯乙烯護套銅絲編織內層總屏蔽銅帶外層總屏蔽變頻電纜。 PVC insulated，PVC sheathed， copper braid inner layer collectively screened, and copper tape outer layer collectively screened power supply conversion cable.
BPYJVPP2	交聯聚氯乙烯絕緣聚氯乙烯護 套銅絲編織內層總屏蔽銅帶外層總屏蔽變頻電纜。 XLPE insulated, PVC sheathed， copper braid inner layer collectively screened, and copper tape outer layer collectively screened power supply conversion cable.
BPYJYPP2	交聯聚氯乙烯絕緣聚烯烴護套銅絲編織內層總屏蔽銅帶外層總屏蔽變頻電纜。 XLPE insulated,PO sheathed， copper braid inner layer collectively screened, and copper tape outer layer collectively screened power supply conversion cable.
WDZ-BPYJYPP2	交聯聚氯乙烯絕緣聚烯烴護套銅絲編織內層總屏蔽銅帶外層總屏蔽無鹵低煙阻燃變頻電纜。 XLPE insulated,PO sheathed， copper braid inner layer collectively screened, opper tape outer layer collectively screened，halogen-free,low-smoke and flame-retardant power supply conversion cable.

注：BP-變頻的漢語拼音開頭字母

Note:”BP” is the two initial letters of Chinese Pin Yin of conversion.

規格/Specification

相線芯標稱截面

Nominal cross-section Area of Phase Cores

(mm2)

中性線芯標稱截面

Nominal Cross-section Area of Neutral Cores

(mm2)

2.5

4

6

10

16

25

35

50

70

95

120

150

185

240

300

1

1,1.5

1.5,2.5

2.5,4,6

4,6,10

6,10,16

10,16,25

16,25,35

25,35,50

35,50,70,95

50,70,95,120

70,95,120
