2、產品型號及規格（表1、表2） types(form1 form2) 表1form1
|
型號 type |
名稱 name |
|
FZ-VV—0.6/1 |
額定電壓0.6/lkV聚氯乙烯絕緣及護會顱制分支電纜 rated voltage0 6/lkV PVCinsulation and sheath pre-fabricated branchcd cable |
|
FZ-ZRVV-0.6/1 |
額定電壓0.6/lkV聚氯乙烯絕緣及護套阻燃預制分支電纜 rated voltage 0.6/lkV PVC insulation and sheath flame-retardant pre-fabricated branched cable |
|
FZ-NHVV-0.6/1 |
顴定電壓0.6/1 kV聚氯乙烯絕緣及護套耐火預制分支電纜 rated voltage 0.6/lkV PVC insulation and sheath fire-resistant pre-fabricated branched cable |
|
FZ-YJV-0.6/1 |
額定電樂0.6/lkV交聯聚乙烯絕緣氯乙烯護套預制分支電纜 rated voltage 0.6/lkV cross-linked polycthylcne insulation and PVC sheath prc- fabricated branched cable |
|
FZ-ZRYJH-0 6/1 |
額定電壓0.6/1 kV交聯聚乙烯絕緣聚氯乙烯護套阻燃預制分支電纜 rated voltage 0.6/1 kV cross-tinked polyethylene insulation and PVC sheath flame-retardant pre- Fabricated branched cable |
|
FZ-N1HYJV-0.6/1 |
額定電壓0.6/lkV交聯聚乙烯絕緣聚氯乙烯護套耐火預制分支電纜 rated voltage0.6/lkVcross-linked polyethylene，nsulationandPVCsheathfire-resistant pre-fabricatedbranched cable |
|
FZ-WDYJV-0.6/1 |
頒定電壓0.6/lkV交聯聚乙烯絕緣聚氯乙烯護套低煙無法，預制分支電纜 rated voltage 0.6/lkV cross-linked polyethylene insulation and PVC sheath LSOH pre- fabricated branched cable |
|
FZ-WDNHYJV-0.6/1 |
額定電壓0:6/lkV交聯聚乙烯絕緣聚氯乙烯護套低煙無鹵耐火預制分支電纜 rated voltageo．6tlkV cross-liriked polyethylene insulation and PVC shea他LSOH fire-resistant pfe- fabricated branChed cahle
|
表2(主干線與表內所列相應的任一支線規格配接)
Form2(main trunk is assorted with any corresponding branch)
|
主干電纜截面 Main cable Section mm2 |
支線纜截面 Branch cable section mm2 |
|||||||||
|
70 95 120 150 185 240 300 400 500 630 |
10 10 10 10 10 10 10 10 10 10 |
16 16 16 16 16 16 16 16 16 16 |
25 25 25 25 25 25 25 25 25 25 |
35 35 35 35 35 35 35 35 35 35 |
50 50 50 50 50 50 50 50 50 |
70 70 70 70 70 70 70 70 |
95 95 95 95 95 95 |
120 120 120 120 120 |
150 150 150 |
185 185 |
3、電纜主要技術參數
3.Cable main technical parameters
0.6/1kV PVC絕緣PVC護套單芯電纜技術參數
0.6/1kV PVC insulation and PVC sheach single-core cable technical parameter
